Water Ingress Test Chamber & Tester Manufacturers, Price India

Brand :Presto Enviro

A water ingress tester is a device that mimics conditions of actual water exposure in the real world. With ingress testing, the quality control team can determine the effectiveness of a product to withstand water penetration. The IPX3 and IPX4 water ingress test equipment can replicate light drizzle, heavy rain, or direct water jets, depending on the IP rating required.

Employing IPX3 water ingress test equipment during the early stages of product design empowers manufacturers to uncover potential sealing vulnerabilities. By detecting these weaknesses beforehand, manufacturers are able to reduce the chances of failures and recalls of their products by a large margin. This initiative increases the dependability of the products and the product quality in general. As a result, the customers are provided with a reliable, long-lasting, and high-quality product that can withstand the weather.

When it comes to certifications, these testers are also helpful in meeting international standards such as IEC 60529, ISO 20653, and JIS D 0203. These standards are essential. It is possible to save a significant amount of time and resources by using water ingress testers because they simulate prolonged water exposure in a controlled and accelerated environment, thereby producing results that are accurate and reproducible.

Technical Specifications

Technical Features of Water Ingress Test Chambers

Adjustable spray pressure (0.1–0.5 MPa) and flow rate for simulating light to heavy water exposure.
Multi-angle nozzles with rotating or tilting platforms for uniform water distribution.
PLC or touchscreen control with programmable cycles, spray patterns, duration, and intervals.
Water temperature control to simulate environmental conditions (10–60 °C).
Corrosion-resistant SUS 304 stainless steel chamber and tank construction.
Closed-loop water circulation with filtration and automatic drainage to prevent nozzle clogging.
Compliance with IPX3–IPX6, IEC 60529, ISO 20653, and JIS D 0203 standards.
Integrated safety systems: leak detection, emergency stop, door interlocks, and observation window.
High-precision monitoring of flow rate, spray angle, and platform rotation for reproducible results.

Water Ingress Tester Specifications

Specification	Details
Internal Chamber Size (W × H × D)	800 × 800 × 800 mm (compact for diverse devices)
External Dimensions (W × H × D)	1200 × 1700 × 1100 mm
Interior Material	SUS 304 Stainless Steel with corrosion-resistant coating
Water Spray Nozzles	Diameter 0.3–0.5 mm for fine droplet simulation (IPX3–IPX4)
Nozzle Spacing	40–60 mm, adjustable for device coverage
Spray Angle	IPX3: vertical dripping at 60° from vertical; IPX4: water spray from all directions, 360°
Water Flow Rate	IPX3: 1.0–1.2 L/min; IPX4: 1.5–1.9 L/min
Oscillation / Rotation	Rotating platform 360° for uniform exposure; adjustable speed 1–4 rpm
Spray Distance	1.5–2.0 m (IPX4 jet simulation)
Turntable / Specimen Table	Diameter 300–500 mm, height adjustable for devices of different sizes
Water System	Closed-loop circulation with fine filtration; automatic drainage to prevent overflow
Control System	PLC or touchscreen for programmable cycles, spray patterns, flow rate, and test duration
Water Temperature Range	Ambient to 60 °C (simulating rain at different environmental conditions)
Safety & Monitoring	Leak detection sensors, emergency stop, observation window, door interlock
Compliance/Standards	IEC 60529 (IPX3–IPX4), ISO 20653, JIS D 0203, relevant product-specific IP testing

Review & Rating

FAQs

What is the use of a water ingress tester?

Water ingress testers simulate water exposure to evaluate product waterproofing and sealing. They help manufacturers identify weaknesses and ensure products withstand real-world wet conditions.

How does water ingress test equipment work?

Water ingress test equipment delivers water at controlled pressures, angles, and flow rates onto the test sample. Adjustable nozzles and rotating platforms replicate different rain intensities and water jet conditions to assess performance and durability.

What is the price of water ingress testing equipment in India?

The water ingress testing equipment price typically ranges from INR 1 lakh to 5 lakh. The price depends on chamber size, complexity, automation, flow capacity, and compliance with international standards.

How to find an authentic water ingress tester manufacturer?

Look for manufacturers with ISO or IEC certifications, detailed product specifications, positive industry reviews, strong technical support, and proven quality control.

Where to buy genuine water ingress testers?

Purchase from authorized distributors, certified manufacturers, or trusted industrial equipment marketplaces. Ensure warranty, calibration services, and after-sales support are provided.
